Widely demanded in the market, the offered Excelam Lamination Machine is ideal to laminate almost all kinds of documents. Designed as per international quality standards, this machine is manufactured using premium quality components and advanced techniques at our vendors' end. Also, our quality inspectors stringently test this machine on set quality parameters to ensure its flawless operations. We are offering provided Excelam Lamination Machine to the clients in several technical specifications at pocket friendly prices.
Features:
Easy to operate
Lower power consumption
Precise temperature control
Compact and portable
SPECIFICATIONS:
| Model | 355Q | 655Q | 1055Q |
| Laminating Speed(m) | 1.5m/min | 1.5m/min | 1.5m/min |
| Laminating Width(mm) | 355mm | 655mm | 1055mm |
| Laminating Films | 25mic~500mic | 25mic~500mic | 25mic~500mic |
| Thickness of substrate | 80g/m2~350g/m2 | 80g/m2~350g/m2 | 80g/m2~350g/m2 |
| Thickness Mount | 5mm | 5mm | 5mm |
| Power Requirements | AC 220V-240V, 50/60Hz | AC 220V-240V, 50/60Hz | AC 220V-240V, 50/60Hz |
| Power Consumption | 1400W, 6.0A | 1700W, 7.0A | 2400W, 10.0A |
| Warm Up Time | 10min | 10min | 10min |
| Heating System | Hot Roller Internal Infrared Heater | Hot Roller Internal Infrared Heater | Hot Roller Internal Infrared Heater |
| Operating Temperature | 130oC Max. | 130oC Max. | 150oC Max. |
| Speed Control | Key Pad | Key Pad | Key Pad |
| Temperature Control | Key Pad | Key Pad | Key Pad |
| Pressure Adjustment | Manual(6-preset) | Manual(6-preset) | Manual(6-preset) |
| Film Core | 14-25WH | 14-25WH | 19-58WH |
| Cooling System | Blower | Blower | Blower |
| Dimensions(WXLXH) | 585 X 450 X 285 mm | 885 X 450 X 285 mm | 1285 X 450 X 285 mm |
| Type of Main Motor | DC W-Geared Motor / 36V70 | DC W-Geared Motor / 36V70 | DC W-Geared Motor / 36V70 |
| Stand | n/a | option | option |
